12S 6000mAh 100C LiPO Battery
Description
12S 6000mAh 100C LiPO Battery Specification
Battery Type: 12S LiPO Battery
Nominal Capacity: 6000mAh
Nominal Voltage: 44.4V
Charge Cut-off Voltage: 50.4V
Discharge Cut-off Voltage: 36V
Standard Charge Current: 0.2C (1200mA)
Max Charge Current: 1C (6000mA)
Standard Discharge Current: 0.2C (1200mA)
Max Continuous Discharge Current: 100C (600A)
Max Peak Discharge Current: 200C (1200A)
Cycle Life: More Than 500 Times
Dimensions: 75 × 47 × 279 mm
Weight: 1738g
Charge Temperature Range: 0°C to 45°C
Discharge Temperature Range: -20°C to 65°C
Storage Temperature Range:
- -20℃~25℃: More than 12 months
- -20℃~45℃: Less than 3 months
- -20℃~60 ℃: Less than 1 month
Charge Connector: JST-XH
Discharge Connector: Bare wire, XT60, EC5, Deans etc
✅ Key Features
💥 True 100C Continuous Discharge
Push your 3D helicopter or high-speed RC jet to the limit with 600A of constant power. This is not a labeled number — our cells are stress-tested under load to meet real-world requirements.
🔋 Real 6000mAh Capacity
Unlike inflated marketing specs, our battery is laboratory-tested for true capacity. No shortcuts — just consistent, long-lasting power delivery per cycle.
🧯 Ultra Low Internal Resistance
Each cell is engineered with optimized electrode chemistry for lower resistance, reducing heat generation, increasing safety, and maximizing voltage under load, typically below 5mΩ per cell, ensuring minimal energy loss and heat generation. This translates to:
-
Stable voltage delivery under high loads
-
Enhanced efficiency for maximum power output
-
Longer battery lifespan with reduced wear during high-discharge cycles
🪶 Lightweight Design, Optimized Cell Matching
Despite its size and voltage, the battery remains weight-conscious, perfect for aerial platforms where every gram matters.
🧰 Customizable:
Stand out with customizable labels tailored to your brand or team. Whether you’re a hobbyist, professional pilot, or reseller, we offer low minimum order quantities to make personalization accessible and cost-effective. Showcase your unique style or business logo without the need for large bulk orders.
🚁 Built for Demanding RC Applications
-
3D Electric Helicopters (600–800 class)
-
High-speed RC Jets & EDFs
-
Long-range heavy-lift FPV drones
-
Professional UAV platforms
-
Racing boats & extreme land RC vehicles
❓ Frequently Asked Questions (FAQ)
1. Can this battery safely handle 100C continuous discharge?
Yes. We use grade-A matched LiPo cells designed for true 100C discharge. Real-world testing confirms continuous performance at full current without swelling or failure under thermal load.
2. How is this different from a typical 12S 6000mAh 50C battery?
A 100C battery can deliver twice the current with less voltage sag, cooler temps, and better throttle response, which is critical in 3D aerobatics and rapid directional changes.
3. Will it fit in my 700-class or 800-class helicopter?
Yes, the dimensions are optimized for most standard battery trays and fuselage compartments in 700/800-class 3D helis (e.g., SAB Goblin, Align T-REX, Goosky RS7). Custom size options are available if needed.
4. Do you offer branding/sticker design services?
Absolutely. We support full OEM customization, including label design, logo printing, and retail-ready packaging—with low minimum order quantities to support small brands and builders.
5. How many charge cycles can I expect?
Under proper usage (charging at ≤1C, storage at 3.65V/cell, no over-discharge), you can expect 500+ cycles while maintaining ≥80% capacity.
