Description

4S 6000mAh 85C LiPo Battery Pack

Model: CP6000HN85-4S

Battery Type: Rechargeable LiPo Battery

Nominal Capacity: 6000mAh

Nominal Voltage: 14.8V

Charge Cut-off Voltage: 16.8V

Discharge Cut-off Voltage: 12V

Standard Charge Current: 0.2C (1200mA)

Max Charge Current: 1C (6000mA)

Standard Discharge Current: 0.2C (1200mA)

Max Continuous Discharge Current: 85C (510A)

Max Peak Discharge Current: 170C (1020A)

Cycle Life: More Than 500 Times

Dimensions: 49 × 47 × 139 mm

Weight: 526g

Charge Temperature Range: 0°C to 45°C

Discharge Temperature Range: -20°C to 65°C

Storage Temperature Range:

• -20℃~25℃: More than 12 months
• -20℃~45℃: Less than 3 months
• -20℃~60 ℃: Less than 1 month

Charge Connector: JST-XH

Discharge Connector: Bare wires, XT60, T Deans, EC5 etc

Cestpower Hard Pack LiPo Battery Model List

Model	Typical Capacity	Typical    Voltage	Thickness  ±0.5mm	Width ±1mm	Length  ±1.5mm	Approx Weight (±1% gram)	C Rating	Max Continuous Discharge Current	Burst Discharge Current	Discharge Connector
CP6000HN100-1S	6000mAh	3.7V	18.5mm	47mm	93mm	128g	100C	600A	1200A	4mm Banana
CP6200HN100-1S	6200mAh	3.7V	18.5mm	47mm	93mm	132g	100C	620A	1240A	4mm Banana
CP7000HN100-1S	7000mAh	3.7V	18.5mm	47mm	93mm	139g	100C	700A	1400A	4mm Banana
CP8300HN100-1S	8300mAh	3.7V	24.9mm	47mm	95mm	162g	100C	830A	1660A	5mm Banana
CP9500HN100-1S	9500mAh	3.7V	24.9mm	47mm	95mm	162g	100C	950A	1900A	5mm Banana
CP3000RN40-2S	3000mAh	7.4V	23.5mm	45.8mm	134mm	125g	40C	120A	240A	T Dean or custom
CP3300HN70-2S	3300mAh	7.4V	23.5mm	46.5mm	138.5mm	200g	70C	231A	462A	5mm Banana
CP4000RN40-2S	4000mAh	7.4V	23.5mm	45.8mm	134mm	210g	40C	160A	320A	T Dean or custom
CP4000HN60-2S	4000mAh	7.4V	24.7mm	46.9mm	93mm	250g	60C	240A	480A	5mm Banana
CP4200HN50-2S	4200mAh	7.4V	24.9mm	47mm	139mm	228g	50C	210A	420A	4mm Banana
CP4200HN85-2S	4200mAh	7.4V	24.9mm	47mm	139mm	228g	85C	357A	714A	T Dean or custom
CP4600HH100-2S	4600mAh	7.6V	24.9mm	47mm	95mm	175g	100C	460A	920A	5mm Banana
CP5000HN60-2S	5000mAh	7.4V	25.1mm	68.5mm	93mm	275g	60C	300A	600A	5mm Banana
CP5200HN50-2S	5200mAh	7.4V	24.9mm	47mm	139mm	248g	50C	260A	520A	T Dean or custom
CP5200HN85-2S	5200mAh	7.4V	24.9mm	47mm	139mm	248g	85C	442A	884A	4mm Banana
CP5200HN100-2S	5200mAh	7.4V	24.9mm	47mm	95mm	212g	100C	520A	1040A	5mm Banana
CP5800HN70-2S	5800mAh	7.4V	25.1mm	68.5mm	93mm	305g	70C	392A	784A	5mm Banana
CP6000HN50-2S	6000mAh	7.4V	24.9mm	47mm	139mm	275g	50C	300A	600A	4mm Banana
CP6000HN85-2S	6000mAh	7.4V	24.9mm	47mm	139mm	275g	85C	510A	1020A	T Dean or custom
CP5500HH100-2S	5500mAh	7.6V	24.9mm	47mm	95mm	216g	100C	550A	1100A	5mm Banana
CP6000HH120-2S	6000mAh	7.6V	24.9mm	47mm	95mm	245g	120C	720A	1440A	5mm Banana
CP6800HN50-2S	6800mAh	7.4V	24.9mm	47mm	139mm	300g	50C	340A	680A	4mm Banana
CP6800HN85-2S	6800mAh	7.4V	24.9mm	47mm	139mm	300g	85C	578A	1156A	4mm Banana
CP7000HH120-2S	7000mAh	7.6V	22.0mm	47mm	139mm	353g	120C	840A	1680A	5mm Banana
CP8000HN70-2S	8000mAh	7.4V	25.1mm	46.5mm	138.5mm	315g	70C	560A	1120A	5mm Banana
CP4000HN85-3S	4000mAh	11.1V	38mm	46.5mm	138mm	304g	85C	340A	680A	T Dean or custom
CP4000HN50-3S	4000mAh	11.1V	38mm	46.5mm	138mm	304g	50C	200A	400A	T Dean or custom
CP4500HN50-3S	4500mAh	11.1V	38mm	46.5mm	138mm	353g	50C	225A	450A	T Dean or custom
CP4800HN85-3S	4800mAh	11.1V	38mm	46.5mm	138mm	376g	85C	408A	816A	T Dean or custom
CP5000HN40-3S	5000mAh	11.1V	35mm	46mm	138mm	390g	40C	200A	400A	T Dean or custom
CP5500HN50-3S	5500mAh	11.1V	38mm	46.5mm	138mm	411g	50C	275A	550A	T Dean or custom
CP5500HN85-3S	5500mAh	11.1V	38mm	46.5mm	138mm	411g	85C	467.5A	935A	T Dean or custom
CP6000HN50-3S	6000mAh	11.1V	38mm	46.5mm	138mm	433g	50C	300A	600A	T Dean or custom
CP6500HN85-3S	6500mAh	11.1V	38mm	46.5mm	138mm	458g	85C	552.5A	1105A	T Dean or custom
CP4500HN50-4S	4500mAh	14.8V	49mm	47mm	139mm	232g	50C	225A	450A	T Dean or custom
CP4500HN85-4S	4500mAh	14.8V	49mm	47mm	139mm	232g	85C	382.5A	765A	T Dean or custom
CP5600HN50-4S	5600mAh	14.8V	49mm	47mm	139mm	493g	50C	280A	560A	T Dean or custom
CP6000HN85-4S	6000mAh	14.8V	49mm	47mm	139mm	526g	85C	510A	1020A	T Dean or custom
CP6500HN50-4S	6500mAh	14.8V	49mm	47mm	139mm	584g	50C	325A	650A	T Dean or custom
CP6800HN85-4S	6800mAh	14.8V	49mm	47mm	139mm	598g	85C	578A	1156A	T Dean or custom
CP7200HN85-4S	7200mAh	14.8V	49mm	47mm	139mm	623g	85C	612A	1224A	T Dean or custom
CP7500HN50-4S	7500mAh	14.8V	49mm	47mm	139mm	639g	50C	375A	750A	T Dean or custom

Note:

HN: lipo battery with hard case

HH: high voltage (3.8V/3.85V) lipo battery with hard case

RN: lipo battery with round hard case.
