60V 20Ah Lithium Battery for Electric Scooter
Description
Summary of 60V 20Ah Lithium Ion Battery
60V 20Ah Lithium Battery for Electric Scooter – High Capacity, Safe & Space-Saving Power
The 60V 20Ah Lithium Battery for Electric Scooter is engineered with advanced 21700 5000mAh high-capacity cells, delivering superior energy storage and efficiency compared to traditional 18650 packs. By using 21700 cells, this battery requires fewer parallel connections, saves space, reduces risks, and ensures better stability. With low internal resistance, advanced BMS protection, active cell balancing, and long cycle life, it is the ideal energy solution for high-performance e-scooters.
Lithium Battery 60V 20Ah Parameter
Name: 60V 20Ah Battery
Battery Cell: 21700 5000mAh
Connection: 16S4P
Nominal Voltage: 60V (59.2V)
Nominal Capacity: 20Ah
Energy: 1200Wh
Charge Cut-off Voltage: 67.2V
Discharge Cut-off Voltage: 44V
Max Continuous Discharge Current: 30A
Peak Discharge Current: 60A
Max Charging Current: 10A
Cycle Life: ≥500 Cycles @80% DOD
Weight: 5.6kg
Size: 356*90*76 mm
Charging Temperature: 0°C to 60°C
Operating Temperature: -20°C to 60°C
✅ Key Features & Advantages
21700 Large-Capacity Cells
Built with 5000mAh 21700 cells instead of 18650. For example, assembling a 60V 20Ah pack with 18650 cells (3350mAh) requires 16S6P,
while with 21700 cells it only needs 16S4P. This reduces the number of cells, lowers risks, and saves valuable space.
Low Internal Resistance
Minimal energy loss and less heat generation. Ensures efficient power drain, stable performance, and boost battery life when frequently using.
Advanced BMS Protection
Integrated battery management system with overcharge, over-discharge, over-temperature, short-circuit, and reverse-polarity protection.
Active Balancing Function
Prevents large voltage differences between cells. Protects capacity from sudden drops, guarantees stable working conditions, and prolongs lifespan.
Long Cycle Life
More than 500 charge cycles, retaining 80%+ capacity. Cost-saving and durable, making it suitable for both daily commuting and long-distance scooter use.
Customizable Options
Available in multiple shapes (rectangular, cylindrical, triangular, arc), voltages, capacities, connectors, and OEM services (printing, labels, packaging).
Perfectly adaptable for different electric scooter models and design requirements.
🚴 Applications
✅ Electric scooters (urban, long-range, and performance models)
✅ High-power mobility devices
✅ Lightweight electric motorcycles
✅ Outdoor commuting and recreational riding
✅ Custom e-mobility projects
❓ FAQ
Q1: Why use 21700 cells instead of 18650?
A1: 21700 cells have higher capacity (5000mAh), meaning fewer cells are required for the same pack, reducing parallel groups, saving space, and lowering risks of imbalance.
Q2: How long will this 60V 20Ah lithium battery last?
A2: It delivers over 500 cycles while maintaining at least 80% capacity, ensuring years of reliable use.
Q3: Is the battery safe for daily use?
A3: Yes, with advanced BMS protection and active balancing, it provides stable and safe performance under various conditions.
Q4: Can the discharge current be customized?
A4: Yes, the standard supports 30A continuous discharge, but higher outputs can be customized upon request.
Q5: Do you provide OEM customization?
A5: Absolutely. We offer custom sizes, voltages, labels, packaging, and connectors to match your scooter brand or design.
