Samsung 18650 30Q 3000mAh 15A Rechargeable Lithium ion Battery Cell INR18650 3.7V for Flashlight Vape E-bike

Description



Model name : INR18650-30Q, lithium-ion rechargeable cell 18650 3000mAh 30Q battery cell is made by Samsung SDI Co., Ltd. Energy Business Division.

Nominal discharging capacity: 3Ah

Charging: 1.5A, 4.2V,CC and CV 0.15A cut off

Discharging: 0.2C, 2.5V discharging cut off

Nominal volt: 3.6V

Standard charging: CC and CV, 1.5A, 4.2V ± 0.05, 0.15A cut off

Rapid charging: CC and CV, 4A, 4.2V± 0.05, 0.1A cut off

Charging time: Standard charging : 3 hours at 0.15A cut off

Rapid charging: 1hour and 10mins (at 25℃) at 0.1A cut off

Maximum continuous discharging: 15A at 25℃, 60 percents at 250 cycle.

Discharging cut off volt / end of discharging: 2.50V

Cell weight: 48g maximum

Cell dimension: Height : 64.85mm ± 0.15

Diameter : 18.33mm ± 0.07

Operate temperature (for battery cell): Charging : 0 to 50℃ (suggested recharge release less than 45℃)

Discharging: -20 to 75℃ (suggested re-discharge release less than 60℃)

Storage temperature (Recovery 90% after storage)：18 months -30 to 25℃

3 months -30 to 45℃

1 month -30 to 60℃

Note : If the cell is keeping as ex factory status (50%±5 SOC, 25℃), the capacity recovery rate is more than 90% of 10A discharging capacity, 100% is 2.9Ah at 25℃ with SOC 100% after formation

Standard testing condition

Environmental conditions:  Unless otherwise specified, all tests stated in this specification are conducted at temperature 25℃±5 and humidity 65%±20

Measurement equipment

1, Ampere meter and volt meter:  The ampere meter and volt meter should have an accuracy of the grade 0.5mA and mV or higher.

2, Slide caliper:  The slide caliper must has 0.01mm scale

3, Resistance meter:  The Resistance meter with AC 1kHz.

Specification

Standard charging

It is to charge the cell CC and CV with charging current 0.5C (1.5A), constant volt 4.2V and 0.15A cut off at CV mode at 25℃ for capacity

Rapid charging

This is to charge the cell CC and CV with charging current 4A and 0.1A cut off at 25℃

Nominal discharging capacity

The standard discharging capacity is the initial discharging capacity of the cell, which is measured with discharging current at 0.6A (0.2C) with 2.50V cut off at 25℃ within 1hour after the standard charge.

Nominal discharging capacity exceed 3Ah, comply to min capacity of IEC61960 standard.

Standard rated discharging capacity

The standard rated discharging is the discharging capacity of battery cell, which is gauged at discharging current of 10A and 2.5V cut off at 25℃ within 1hour after the standard charge.

Standard rated discharging capacity more than 2.9Ah

Initial internal resistance (IR)

Initial internal resistance measured at AC 1kHz after standard charging

Initial internal resistance less than 26mΩ

Cycle life

At standard charging and maximum continuous discharging

Capacity more than 1.8Ah (60 percents of nominal capacity at 25℃)

Storage characteristics

Standard rated discharging capacity after storage for 1 month at 60℃ from the standard charged state is ≥ 90% of the initial 10A discharging capacity at 25℃

Battery cell voltage at shipment

The cell is 3.62V to 3.69V charging volt range at shipment.
