Description

Key Features

• Light weight
• Built-in 200A BMS & Multiple Protection
• Long Cycle Life
• CAN, RS485, Bluetooth Communication

Parameter

Nominal Voltage: 48V (51.2V)

Rated Capacity: 105Ah

Energy: 5376Wh

Charge Cut-off Voltage: 58.4V

Discharge Cut-off Voltage: 43.2V

Max Continuous Discharge Current: 200A

Peak Discharge Current: 400A

Max Charging Current: 100A

Cycle Life: ≥4000 Cycles @80% DOD

Communication: CAN, RS485, Bluetooth

Waterproof: IP67

Weight: 46.7kg (103lbs)

Size (L×W×H): 520*322*245mm  (20.5*13.1*9.6 in)

Charging Temperature: 0°C to 60°C

Operating Temperature: -20°C to 60°C
