Top Battery Supplier Based in China
NiMH Battery Pack: Rechargeable nickel-metal hydride solutions. High capacity, low self-discharge, high current and environmentally friendly. Ideal for rc cars, consumer electronics, power tools, and more. Our selection offers long-lasting performance and safety for your devices. Reliable and cost-effective.
Showing all 8 results
Battery Model: AA, AAA, C, SC, D, F and so on Voltage: 1.2V to 24V and more Capacity: can be in parallel with any cells Size: Customizable OEM: Acceptable, we can stick specified words or custom labels Battery cell type as below. What are NiMH Battery Packs? NiMH battery packs are rechargeable batteries that…
Parameters Nominal Voltage: 12.0V Open Circuit Voltage (OCV): ≥12.5V Rated Capacity: 4500mAh Minimum Capacity: 4400mAh Internal Impedance: ≤350mΩ Cycle Life: ≥500 Standard Charge: 0.1C 450mAh Fast Charge: 0.5C 2250mAh Trickle Charge: 0.05C 225mAh Discharge Cut-Off Voltage: 9.6V Maximum Continuous Discharge Current: 2C 9A Rapid Discharge: ≥54 Min Storage Temperature: -20-50°C, less than 30 days -20-40°C, less than 90 days -20-30°C, less than 360 days Storage Humidity: 65±20% Self…
Parameters Battery Type: Ni-MH Battery Nominal Voltage: 4.8V (can be custimized to other voltage) Charge Voltage: 6.0V Open Citcuit Voltage(OCV): ≥5.5V (Within 1 hr after standard charge) Nominal Capacity: 500mAh (can be customized to other capacity) Minimum Capacity: 460mAh Standard Charge: 0.1C 50mA Trickle Charge: 0.05C 25mA Maxmum Continuous Discharge Current: 1C 500mA Internal Impedance(Ri): ≤145mΩ (Upon…
Understanding Voltage and Capacity Before delving into the differences between the three types of NiMH batteries, it’s essential to understand voltage and capacity. Voltage refers to the amount of electrical potential energy that a battery can provide, while capacity refers to the amount of electrical charge a battery can hold. Voltage is measured in volts…
Custom rechargeable battery pack utilize lithium chemistry provides both high voltage and excellent capacity, leading to a unprecedented high density. most applications, like cell phones, medical devices, electric vehicles, require such high density that only lithium chemistry can reach. However, for some applications we see, custom Nickel Metal Hydride/NiMH battery packs are more cost…
Battery Type: NiMH Hump Battery Battery Voltage: 8.4V Capacity:3000mAh to 5000mAh Size: 46*47*137mm 1.81*1.85*5.39 Inch Maximum Charge Rate: 1C Maximum Discharge Rate: 10C Weight: 420g to 520g (14.81oz to 18.34oz) Wire Gauge: 12 AWG or more powerful Connector: Traxxas, T dean or others What is an 8.4V Hump NiMH battery? An 8.4V Hump NiMH…
Parameters Name: Nickel Cadmium (NiCd) battery Battery Model: AA Ø 14*L 50 mm Battery Cell Voltage: 1.2V Nominal Voltage: 6.0V Nominal Capacity: 700mAh Cut-off Voltage: 4.5V Charge Voltage: 8.0V Internal Impedance: <170mΩ Dimension: 32*45*56mm Weight: 380g Cycle Life: Minimum 500 times Charge Current: Trickle: 35mA Standard: 70mA Quick: 700mA Charge Temperature: Standard Charge: 0-45°C Quick Charge:…
Battery for RC model Receiver and Transmitter, the battery voltage range 4.8v 6.0v 7.2v etc, mainly use battery model 2/3A NiMH battery cell. 1000mAh to 2000mAh. Characteristics of NiMH Batteries NiMH (Nickel Metal Hydride) batteries are rechargeable batteries that are commonly used in RC receiver applications due to their high energy density and low…
